| THERMAL IMAGING PERFORMANCE |
| Sensor type | 640 x 480 VOx microbolometer |
| Field of view | 7° (horiz), 14° (horiz) selectable |
| Spectral band | 7.5-13.5 μm |
| Automatic features | Contrast, brightness |
| |
| SYSTEM FEATURES |
| Silent operation | Inaudible beyond 1 m |
| Bore sight retention | Holds boresight through extensive rounds of firing on a variety of weapon platforms |
| | |
| OUTPUTS |
| Video | Built in Display VGA monochrome and external video out |
| | |
| POWER |
Power requirements | 4 CR123 batteries or 12V DC remote power supply |
| Battery Life | Approximately 5 hours continuous use |
| |
| ENVIRONMENTAL |
| IP rating | IP 67+ (66 ft. seawater, 2 hours) |
| Operating temp | 40°C to +55°C (-40°F to +131°F) |
| Storage temp | -50°C to +65°C (-58°F to +149°F) |
| Dimensions | 8.25 in l x 6.14 in w x 3.9 in h |
| Shock and vibe | Per MIL-STD-810G |
| | |
| DIMENSIONS, WEIGHT & MOUNTING |
| Dimensions (lens covers off) | 6.0” L x 3.25” W x 4.0” H |
| Weight | 1.5 lbs with batteries and lens covers |
| Mounting | Picatinny Rail mount |
| | |
| INTERFACES |
| Command and Control | Auto gain/level, polarity, manual NUC, 1x zoom (7° FOV), 0.5x zoom (14° FOV) |
| | |
| STANDARD PACKAGE |
| Batteries | 4 each, CR123, fit into plastic sleeve for quick removal and replacement |
| | |
| OPTIONS |
| Laser Pointer | NVG compatible laser pointer. Class 1 (0.5 mW)/Class 3b (30 mW) selectable with remote pressure pad switch
|
