The Argus4 LITE range of thermal imaging cameras are a low cost, high quality solution to meet the needs of every firefighter. The camera uses the same highly successful detector used in the standard Argus4, but it allows the end-user to customise their camera with the features they want.
The Argus4 LITE cameras are compatible with all Argus4 optional accessories with the exception of the transmitter battery pack and external power and video adapter.
The ArgusTM4Lite Thermal Imaging Camera is a low cost,
high quality solution to meet the needs of every firefighter.
The ArgusTM4Lite uses the same highly successful
Amorphous Silicon (ASi) Microbolometer Detector used in
the ArgusTM4 but allows the end-user to customise their
camera to the features they require.
The ArgusTM4Lite is a simple to operate, robust, selfcontained
camera, which has fully automatic operation; no
control or adjustment, is required in use. The camera has
been specifically designed to help firefighters to see through
smoke, identify and rescue casualties and locate hot spots
or the seat and spread of the fire.
The ArgusTM4Lite is constructed from high quality Radel®R-
5100, which has been chosen for its strength, resistance to
heat, water and impact. Protection from shock is provided
by a combination of rugged components, optimum
mechanical design and protective bumpers. The camera is
sealed to allow short-term total immersion in water (IP67).
No end-user maintenance is required other than recharging
of batteries and post-use external cleaning with a soft cloth.
Power for the ArgusTM4 is provided by an integral battery
pack located on the top of the camera. The camera has a
single on/off button with a delayed off operation to prevent
accidental power-down during use. The camera will display
a start-up screen until a usable thermal image is produced.
CAMERA STANDARD FEATURES
- Tri-Mode Sensitivity for increased temperature range
performance.
- Colour battery level indicator.
- User replaceable external fittings.
STANDARD ACCESSORIES
- Soft carry bag
- Side straps
- One rechargeable battery
- AC or DC battery charger
- Operating instructions
OPTIONAL FEATURES
The ArgusTM4Lite can be supplied with the same advanced
features available on the ArgusTM4. These features include:
- Dynamic Scene Colorisation. (DSC) -
Colorises the thermal image to allow the firefighter to
pinpoint the hottest areas within the fire scene and is set
up by the use of a supplied remote control.
- Direct Temperature Measurement (DTM) -
Displays both the temperature of objects within a defined
area of the thermal scene and also the ambient
temperature of the environment using a sensor mounted
on the front of the camera.
The above features can be supplied with the camera at time
of purchase or added as an after sales upgrade.
WARRANTY
• The camera is supplied with a 2-year warranty as
standard.
• Warranty can be extended for up to three years at time
of purchase.
CONFIGURATION
Camera Order Code
- ArgusTM4Lite P7030/LT
- ArgusTM4Lite + DSC Option P7030/LT/C
- ArgusTM4Lite + DTM Option P7030/LT/S
- ArgusTM4Lite + DSC + DTM Option P7030/LT/SC
Optional Accessories Order Code
- Station Battery Charger P7030BC and P7030CS
- Truck Battery Charger P7030TBC
- Truck Storage Mount P7030TSM
- Truck Storage Mount and
- Battery Charger
- P7030TSMBC
- Rechargeable Battery Pack P7030R
- Handle P7030HA
- Neck Strap P7030NS
- Retractable Lanyard P7030RL
- Hard Carry Case P7030HC
The Argus4 LITE cameras are compatible with all Argus4 optional accessories with the exception of the transmitter battery pack and external power and video adapter.
Dynamic Scene Colourisation (DSC) Colourises the thermal image to allow the firefighter to pinpoint the hottest areas within the fire scene and is set up by the use of a supplied remote control.
Direct Temperature Measurement (DTM) Displays both the temperature of objects within a defined area of the thermal scene and also the ambient temperature of the environment using a sensor mounted on the front of the camera.
